Compressed air dryer APX 6 3/4" 600 l/min
€1,062.00
Incl. Tax:
€1,062.00
Incl. Tax:
Incl. Tax:
Out of stock
SKU
390006
Product details
| SKU | 390006 |
|---|---|
| EAN 13 | 08712418362695 |
| Weight (netto) (kg) | 19 kg |
| Length (mm) | 350 mm3.5 dm |
| Width (mm) | 493 mm4.93 dm |
| Height (mm) | 450 mm4.5 dm |
| Type | APX |
| Control panel | Digital |
| Air flow at 7 bar (l/min) | 600 |
| Air flow at 7 bar (m3/h) | 36 m³/h1.667 L/m |
| Purity class - humidity (ISO 8573-1) | 4 |
| Connection type | Male |
|---|---|
| Air connection (") | 3/4 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| Power (kW) | 0.164 |
| Refrigerant | R513A |
| Maximum pressure (bar) | 16 |
| Pressure dew points (°C) | 4 (+/-1) |
| Max. inlet air temperature (°C) | 55 °C |
| Minimum ambient temperature (°C) | 5 |
| Maximum ambient temperature (°C) | 43 |
