Silent oil free Compressor LMO 50-270 8 bar 2 hp 50 l
Out of stock
SKU
36504
| Motor power (hp / kW) | 2 HP (2x1HP)/ 1.5 kW |
|---|---|
| Capacity air receiver (l) | 50 |
| Maximum pressure (bar) | 8 |
| Intake capacity (l/min) | 256 L/min4.267 L/s |
| Free air delivery (l/min)* | 185 L/min3.083 L/s |
| Noise level dB (A) (0 m) | 78 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| EAN 13 | 8712418394283 |
|---|---|
| Manufacturer | Airpress Polska Sp. z o.o. |
| Weight (netto) (kg) | 55 kg |
| Length (mm) | 785 mm7.85 dm |
| Width (mm) | 355 mm3.55 dm |
| Height (mm) | 660 mm6.6 dm |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor power (hp / kW) | 2 HP (2x1HP)/ 1.5 kW |
| Cylinders | 4 |
| Stages | 1 |
| Pump speed (rpm) | 1450 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 50 |
| Galvanized tank | No |
| Workload (labor/rest %) | 20/80 |
| Maximum pressure (bar) | 8 |
| Minimum working pressure (bar) | 6 bar |
| Intake capacity (l/min) | 256 L/min4.267 L/s |
|---|---|
| Free air delivery (l/min)* | 185 L/min3.083 L/s |
| Free air delivery (m3/h)* | 11.1 m³/h3.083 dm³/s |
| Noise level dB (A) (0 m) | 78 |
| Noise level dB(A) (4 m) | 58 |
| Noise level dB(A) (7 m) | 53 |
| Sound volume reduction | Yes |
| Connection type | Universal |
| Number of couplings air connections | 1 |
| Number of reducable couplings air connections | 1 |
| Oilfree | Yes |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | No |
| Intercooler | No |
| Wheels | Yes |
| Filter with reducer | Yes |
| SKU | 36504 |
* The output efficiency (l/min) is an estimated value, dependent on factors such as the intake air pressure, temperature, and humidity.
