Compressor oil free H 215-6 8 bar 1.5 hp 92 l/min 6 l
€132.16
Incl. Tax:
€132.16
Incl. Tax:
Incl. Tax:
Out of stock
SKU
36943
Product details
| SKU | 36943 |
|---|---|
| EAN 13 | 8712418293678 |
| Weight (netto) (kg) | 10.8 kg |
| Gross weight (kg) | 11 kg |
| Length (mm) | 380 mm3.8 dm |
| Width (mm) | 280 mm2.8 dm |
| Height (mm) | 240 mm2.4 dm |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor power (hp / kW) | 1.5 HP / 1.1 kW |
| Cylinders | 1 |
| Stages | 1 |
| Pump speed (rpm) | 3450 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 6 |
| Galvanized tank | No |
| Workload (labor/rest %) | 20/80 |
| Maximum pressure (bar) | 8 |
| Cut-in pressure (bar) | 6 bar |
|---|---|
| Intake capacity (l/min) | 126 L/m45.36 m³/min |
| Free air delivery (l/min) | 92 L/m33.12 m³/min |
| Free air delivery (m3/h) | 5.52 m³/h1.533 dm³/s |
| Noise level dB (A) (0 m) | 96 |
| Noise level dB(A) (4 m) | 76 |
| Noise level dB(A) (7 m) | 71 |
| Sound volume reduction | No |
| Main air connection (") | 1/4 |
| Number of couplings air connections | 1 |
| Number of reducable couplings air connections | 1 |
| Oilfree | Yes |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | No |
| Intercooler | No |
| Wheels | No |
| Filter with reducer | No |
Recommended
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
Documents & Manuals
Download PDF
Spare parts list 36943
Manual EN/FR/NL/DE/PL 36943
Manual EN/FR/DE/NL/PL/CZ/EE/LV/RO/SK/ES/RU 36578,36577,36854,36862,360578,36504,36753,36747,36588,36587,36750,36738,36743,36741-K1,36943,36748,36576,36575
manual_36943_SET.pdf
OIL_FREE_COMPRESSORS_2025 - WEB.pdf
36943 - SPARE PARTS LIST 2024.pdf
