Screw compressor EcoPower 30D IVR Dry 13 bar 30 HP/22 kW 822 - 3924 l/min
€21,664.80
Incl. Tax:
€21,664.80
Incl. Tax:
Incl. Tax:
Out of stock
SKU
36678529-IVR
Product details
| SKU | 36678529-IVR |
|---|---|
| EAN 13 | 8712418424492 |
| Units per product (pcs.) | 1 |
| Weight (netto) (kg) | 420 kg |
| Length (mm) | 1,450 mm1.45 m |
| Width (mm) | 835 mm8.35 dm |
| Height (mm) | 1,220 mm1.22 m |
| Drive | Direct driven 1:1 |
| Start | Inverter |
| Motor power (hp / kW) | 30.0 HP / 22.0 kW |
| Air-end | C67 |
| Variable speed (IVR) | Yes |
| Control panel | ES 4000 STANDARD |
| Air Receiver | No |
| Galvanized tank | No |
| Dryer | Yes |
| Workload (labor/rest %) | 100/0 |
|---|---|
| Maximum pressure (bar) | 13 |
| Free air delivery at 7 bar (l/min) | 3,924 L/m6.54 L/h |
| Free air delivery at 9.5 bar (l/min) | 3,366 L/m5.61 L/h |
| Minimum free air delivery (l/min) | 822 L/m1.37 L/h |
| Minimum free air delivery (m3/h) | 49.3 m³/h2.282 L/m |
| Maximum free air delivery (l/min) | 3,924 L/m6.54 L/h |
| Maximum free air delivery (m3/h) | 235.6 m³/h3.927 m³/min |
| Noise level dB (A) (0 m) | 71 |
| Noise level dB(A) (4 m) | 51 |
| Maximum ambient temperature (°C) | 46 |
| Oilfree | No |
| Plug type | EU |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| IP classification | IP55 |
