Silent oil free Compressor LMO 3-210 10 bar 0.7 hp 125 l/min 3 l
Out of stock
SKU
36748
| Motor power (hp / kW) | 0.7 HP / 0.5 kW |
|---|---|
| Capacity air receiver (l) | 3 |
| Maximum pressure (bar) | 10 |
| Intake capacity (l/min) | 210 L/min3.5 L/s |
| Free air delivery (l/min)* | 168 L/min2.8 L/s |
| Noise level dB (A) (0 m) | 74 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| EAN 13 | 8712418257397 |
|---|---|
| Manufacturer | Airpress Polska Sp. z o.o. |
| Weight (netto) (kg) | 13 kg |
| Length (mm) | 450 mm4.5 dm |
| Width (mm) | 250 mm2.5 dm |
| Height (mm) | 260 mm2.6 dm |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor power (hp / kW) | 0.7 HP / 0.5 kW |
| Cylinders | 2 |
| Stages | 1 |
| Pump speed (rpm) | 2800 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 3 |
| Galvanized tank | No |
| Workload (labor/rest %) | 20/80 |
| Maximum pressure (bar) | 10 |
| Minimum working pressure (bar) | 8 bar |
| Intake capacity (l/min) | 210 L/min3.5 L/s |
|---|---|
| Free air delivery (l/min)* | 168 L/min2.8 L/s |
| Free air delivery (m3/h)* | 10.08 m³/h2.8 dm³/s |
| Noise level dB (A) (0 m) | 74 |
| Noise level dB(A) (4 m) | 54 |
| Noise level dB(A) (7 m) | 49 |
| Sound volume reduction | Yes |
| Connection type | Universal |
| Main air connection (") | 1/4 |
| Number of reducable couplings air connections | 1 |
| Oilfree | Yes |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | No |
| Intercooler | No |
| Wheels | No |
| Filter with reducer | No |
| SKU | 36748 |
* The output efficiency (l/min) is an estimated value, dependent on factors such as the intake air pressure, temperature, and humidity.
