36596
€177.00
Incl. Tax:
€177.00
Incl. Tax:
Incl. Tax:
Out of stock
SKU
36596
Product details
| SKU | 36596 |
|---|---|
| EAN 13 | 8712418435979 |
| Units per product (pcs.) | 1 |
| Weight (netto) (kg) | 60 kg |
| Length (mm) | 650 mm6.5 dm |
| Width (mm) | 560 mm5.6 dm |
| Height (mm) | 1,165 mm1.165 m |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor type | 4-poles |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Motor efficiency class | S3 - 75% |
| Cylinders | 4 |
| Stages | 1 |
| Pump speed (rpm) | 1400 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 90 |
| Galvanized tank | No |
| Workload (labor/rest %) | 70/30 |
| Maximum pressure (bar) | 10 |
|---|---|
| Cut-in pressure (bar) | 8 bar |
| Intake capacity (l/min) | 440 L/m2.64 kL/s |
| Free air delivery (l/min) | 350 L/m2.1 kL/s |
| Free air delivery (m3/h) | 20.4 m³/h5.667 dm³/s |
| Noise level dB (A) (0 m) | 94 |
| Noise level dB(A) (4 m) | 73 |
| Sound volume reduction | No |
| Connection type | Universal |
| Number of couplings air connections | 1 |
| Number of reducable couplings air connections | 1 |
| Ambient temperature (°C) | 5℃ - 30℃ |
| Oilfree | Yes |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| Cable length (m) | 1.8 m |
| After cooler | No |
| Intercooler | No |
| Wheels | Yes |
| Filter with reducer | No |
