Compressor LM 50-350 10 bar 3 hp 280 l/min 50 l
€784.70
Incl. Tax:
€784.70
Incl. Tax:
Incl. Tax:
Out of stock
SKU
36827
Product details
| SKU | 36827 |
|---|---|
| EAN 13 | 8712418343205 |
| Weight (netto) (kg) | 50 kg |
| Length (mm) | 760 mm7.6 dm |
| Width (mm) | 460 mm4.6 dm |
| Height (mm) | 680 mm6.8 dm |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Cylinders | 2 |
| Stages | 1 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 50 |
| Galvanized tank | No |
| Workload (labor/rest %) | 40/60 |
| Maximum pressure (bar) | 10 |
| Cut-in pressure (bar) | 8 bar |
| Intake capacity (l/min) | 328 L/m1.968 kL/s |
|---|---|
| Free air delivery (l/min) | 245 L/m1.47 kL/s |
| Free air delivery (m3/h) | 14.7 m³/h4.083 dm³/s |
| Noise level dB (A) (0 m) | 96 |
| Noise level dB(A) (4 m) | 76 |
| Noise level dB(A) (7 m) | 71 |
| Sound volume reduction | No |
| Connection type | Universal |
| Main air connection (") | 1/4 |
| Number of reducable couplings air connections | 1 |
| Oilfree | No |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | No |
| Intercooler | No |
| Wheels | Yes |
| Filter with reducer | Yes |
Recommended
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
Documents & Manuals
Download PDF
Spare parts list 36827
Manual EN/FR/NL/DE/PL/ES/UA/CZ/LT/LV/EE/RO/SK/HU 36546, 36744-E, 36839-1, 36856, 36832, 36852, 36833, 36843, 36888, 36834, 36826, 36827, 36828, 36844-E, 36891, 36871, 36872
13.12.2024 - BLUE SERIES PISTON COMPRESSORS OIL LUBRICATED_2024 - WEB.pdf
36827 - SPARE PARTS LIST 2024.pdf
