Standing Compressor 8 bar 2.5 hp 231 l/min 50 l HL 360-50

Out of stock

SKU 36852

none

Product details Recommended Documents Product alternative Reviews Parts

Product details

SKU	36852
EAN 13	8712418191462
Weight (netto) (kg)	36.5 kg
Gross weight (kg)	37 kg
Length (mm)	480 mm4.8 dm
Width (mm)	410 mm4.1 dm
Height (mm)	1,050 mm1.05 m
Drive	Direct driven 1:1
Start	Direct
Motor power (hp / kW)	2.5 HP / 1.8 kW
Cylinders	1
Stages	1
Pump speed (rpm)	2850
Air Receiver	Yes
Capacity air receiver (l)	50
Galvanized tank	No
Workload (labor/rest %)	30/70
Maximum pressure (bar)	8

Cut-in pressure (bar)	6 bar
Intake capacity (l/min)	288 L/m1.728 kL/s
Free air delivery (l/min)	231 L/m1.386 kL/s
Free air delivery (m3/h)	13.86 m³/h3.85 dm³/s
Noise level dB (A) (0 m)	97
Noise level dB(A) (4 m)	77
Noise level dB(A) (7 m)	72
Sound volume reduction	No
Connection type	Universal
Number of couplings air connections	1
Number of reducable couplings air connections	1
Oilfree	No
Voltage (V)	230 V / 50 Hz / 1 Ph
After cooler	No
Intercooler	No
Wheels	Yes
Filter with reducer	No
