36874
Out of stock
SKU
36874
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
|---|---|
| Capacity air receiver (l) | 50 |
| Maximum pressure (bar) | 10 |
| Intake capacity (l/min) | 352 L/min5.867 L/s |
| Free air delivery (l/min)* | 210 L/min3.5 L/s |
| Noise level dB (A) (0 m) | 92 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| EAN 13 | 8712418438437 |
|---|---|
| Manufacturer | Airpress Polska Sp. z o.o. |
| Weight (netto) (kg) | 25 kg |
| Gross weight (kg) | 26 kg |
| Length (mm) | 971 mm9.71 dm |
| Width (mm) | 386 mm3.86 dm |
| Height (mm) | 776 mm7.76 dm |
| Drive | V-belt driven |
| Start | Direct |
| Motor type | AC |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Motor efficiency class | F |
| Cylinders | 2 |
| Stages | 1 |
| Pump speed (rpm) | 1400 |
| Belt size | a-1168 |
| Flywheel diameter (mm) | 280 mm2.8 dm |
| Pulley diameter (mm) | 90 mm9 cm |
| Air Receiver | Yes |
| Capacity air receiver (l) | 50 |
| Galvanized tank | No |
| Workload (labor/rest %) | 30/70 |
| Maximum pressure (bar) | 10 |
|---|---|
| Minimum working pressure (bar) | 8 bar |
| Intake capacity (l/min) | 352 L/min5.867 L/s |
| Free air delivery (l/min)* | 210 L/min3.5 L/s |
| Free air delivery (m3/h)* | 12.65 m³/h3.514 dm³/s |
| Free air delivery at 6 bar (l/min) | 190 L/min3.167 L/s |
| Free air delivery at 7 bar (l/min) | 170 L/min2.833 L/s |
| Noise level dB (A) (0 m) | 92 |
| Noise level dB(A) (4 m) | 71 |
| Connection type | Universal |
| Main air connection (") | 1/4 |
| Number of couplings air connections | 2 |
| Number of reducable couplings air connections | 1 |
| Ambient temperature (°C) | 5℃ - 40℃ |
| Oilfree | No |
| Oil capacity (l) | 0.66 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| Cable length (m) | 2.2 m |
| After cooler | Yes |
| Intercooler | No |
| Wheels | Yes |
| SKU | 36874 |
* The output efficiency (l/min) is an estimated value, dependent on factors such as the intake air pressure, temperature, and humidity.
