Compressor BLM 22-410 10 bar 3 hp 328 l/min 2 x 11 l
€1,242.54
Incl. Tax:
€1,242.54
Incl. Tax:
Incl. Tax:
Out of stock
SKU
36622
Product details
| SKU | 36622 |
|---|---|
| EAN 13 | 8712418320855 |
| Weight (netto) (kg) | 67 kg |
| Length (mm) | 760 mm7.6 dm |
| Width (mm) | 860 mm8.6 dm |
| Height (mm) | 900 mm9 dm |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Cylinders | 2 |
| Stages | 1 |
| Pump speed (rpm) | 1400 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 2 x 11 |
| Galvanized tank | No |
| Workload (labor/rest %) | 50/50 |
| Maximum pressure (bar) | 10 |
| Cut-in pressure (bar) | 8 bar |
| Intake capacity (l/min) | 410 L/m2.46 kL/s |
|---|---|
| Free air delivery (l/min) | 328 L/m1.968 kL/s |
| Free air delivery (m3/h) | 19.68 m³/h5.467 dm³/s |
| Noise level dB (A) (0 m) | 93 |
| Noise level dB(A) (4 m) | 73 |
| Noise level dB(A) (7 m) | 68 |
| Sound volume reduction | No |
| Connection type | 2 Universal + 1 Geka |
| Main air connection (") | 1/4 |
| Number of couplings air connections | 2 - 3 |
| Number of reducable couplings air connections | 1 |
| Oilfree | No |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | No |
| Intercooler | No |
| Wheels | Yes |
| Filter with reducer | Yes |
Recommended
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
Description
With air wheels
