Compressor H 185/6 8 bar 1.5 hp 82.3 l/min 6 l
€169.92
Incl. Tax:
€169.92
Incl. Tax:
Incl. Tax:
Out of stock
SKU
36546
Product details
| SKU | 36546 |
|---|---|
| EAN 13 | 8712418019094 |
| Weight (netto) (kg) | 16 kg |
| Length (mm) | 500 mm5 dm |
| Width (mm) | 240 mm2.4 dm |
| Height (mm) | 470 mm4.7 dm |
| Drive | Direct driven 1:1 |
| Start | Direct |
| Motor power (hp / kW) | 1.5 HP / 1.1 kW |
| Cylinders | 1 |
| Stages | 1 |
| Pump speed (rpm) | 2850 |
| Air Receiver | Yes |
| Capacity air receiver (l) | 6 |
| Galvanized tank | No |
| Workload (labor/rest %) | 30/70 |
| Maximum pressure (bar) | 8 |
| Cut-in pressure (bar) | 6 bar |
|---|---|
| Intake capacity (l/min) | 122 L/m43.92 m³/min |
| Free air delivery (l/min) | 82.3 L/m29.628 m³/min |
| Free air delivery (m3/h) | 4.94 m³/h1.372 dm³/s |
| Noise level dB (A) (0 m) | 80 |
| Noise level dB(A) (4 m) | 60 |
| Noise level dB(A) (7 m) | 55 |
| Sound volume reduction | No |
| Connection type | Universal |
| Main air connection (") | 1/4 |
| Number of reducable couplings air connections | 1 |
| Oilfree | No |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | No |
| Intercooler | No |
| Wheels | No |
| Filter with reducer | No |
Recommended
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
Documents & Manuals
Download PDF
Spare parts list 36546
Manual EN/FR/NL/DE/PL/ES/UA/CZ/LT/LV/EE/RO/SK/HU 36546, 36744-E, 36839-1, 36856, 36832, 36852, 36833, 36843, 36888, 36834, 36826, 36827, 36828, 36844-E, 36891, 36871, 36872
13.12.2024 - BLUE SERIES PISTON COMPRESSORS OIL LUBRICATED_2024 - WEB.pdf
36546 - SPARE PARTS LIST 2024.pdf
