Screw Compressor APS X 15 IVR Combi Dry G2 10 bar 15 HP/11 kW 630 - 1680 l/min 500 l

Name: Screw Compressor APS X 15 IVR Combi Dry G2 10 bar 15 HP/11 kW 630 - 1680 l/min 500 l
SKU: 369213-IVR-G2
Price: 1.18 EUR
Availability: OutOfStock

Out of stock

SKU 369213-IVR-G2

Product details Recommended Documents Product alternative Reviews Parts

Product details

SKU	369213-IVR-G2
EAN 13	8712418428520
Units per product (pcs.)	1
Weight (netto) (kg)	520 kg
Length (mm)	1,902 mm1.902 m
Width (mm)	820 mm8.2 dm
Height (mm)	1,905 mm1.905 m
Drive	Direct driven 1:1
Start	Inverter
Motor type	PM
Motor power (hp / kW)	15.0 HP / 11.0 kW
Motor efficiency class	IE4
Stages	1
Variable speed (IVR)	Yes
Pump speed (rpm)	900 - 1960
Control panel	AirVision One
Available languages	Dutch, Polish, German, French, Spanish, English, Russian
Air Receiver	Yes
Capacity air receiver (l)	500
Galvanized tank	No

Dryer	Yes
Cooling air volume (m3/h)	7,000 m³/h1.944 kL/s
Workload (labor/rest %)	100/0
Maximum pressure (bar)	10
Cut-in pressure (bar)	6 bar
Free air delivery at 7 bar (l/min)	1,680 L/m2.8 L/h
Free air delivery at 8 bar (l/min)	1,590 L/m2.65 L/h
Free air delivery at 9.5 bar (l/min)	1,450 L/m2.417 L/h
Minimum free air delivery (l/min)	630 L/m1.05 L/h
Minimum free air delivery (m3/h)	37.8 m³/h1.75 L/m
Maximum free air delivery (l/min)	1,680 L/m2.8 L/h
Maximum free air delivery (m3/h)	100.8 m³/h1.68 m³/min
Noise level dB (A) (0 m)	63
Noise level dB(A) (4 m)	43
Main air connection (")	1
Oilfree	No
Oil capacity (l)	10
Plug type	EU
Voltage (V)	400 V / 50 Hz / 3 Ph
